Description

Reticle, Type Circle Dot Reticle, Color Red, Green, Black Illuminated (yes/no) Yes Reticle Brightness Setting 0 - 5 Magnification 1 - 6 x Diameter, Objective Lens 24 mm Diameter, Eyepiece 1.65 / 42 (in/mm) Diameter, Exit Pupil .6 - .2 / 14.95 - 4 (in/mm) Diameter, Tube 30 mm Eye Relief 4 / 101.2 (in/mm) Field of view, m@100m 34 - 6.1 Field of view, ft@100yd 102 - 18.2 Diopter Adjustment +2 to -2 Parallax Setting 100 yds Windage Adjustment 100 MOA Elevation Adjustment 100 MOA Windage & Elevation, Lock Yes MOA Adjustment 1/2 MOA Maximum Recoil .338 Win Battery Type CR2032 Battery Life 100 Battery Voltage 3V Sunshade No Nitrogen Filled Yes Shockproof Yes, 3ft Fog Proof Yes Focal Plane Second IP Standard IP67 - Waterproof and Dustproof Lens Coating Fully Multi-Coated Finish/Color Matte Black Body Material Aluminum Operating Temperature -13 to 131 / -25 to 55 (F/C) Length 9.8 / 251 (in/mm) Width 2.4 / 61 (in/mm) Height 1.9 / 47 (in/mm) Weight 14.5 oz
